ENGINE CYLINDER HEAD GASKET SET (ENGINE UPPER GASKET SET)
Code: CR 5143080AB VM
504.59 EUROPRODUCT DESCRIPTION :
UPPER ENGINE GASKET SET (OVERHAUL GASKET SET)
HEAD GASKET NOT INCLUDED
2.8CRD ENGINE
JEEP CHEROKEE/LIBERTY (KJ) 2005-2007
| VM PART# | OEM# | GASKET SET UPPER | QTY |
| 12032271F | 5143080AB | ||
| 22020138A | 4720620 | Shim cylinder liner 0,15 mm | 4 |
| 22020153A | 4720621 | Shim cylinder liner 0,20 mm | 4 |
| 22020154A | 4720622 | Shim cylinder liner 0,25 mm | 4 |
| 22020165A | 4720623 | Shim cylinder liner 0,23 mm | 4 |
| 22022048F | 4863779 | Gasket vacuum pump | 1 |
| 22022049A | 4720624 | Shim cylinder liner 0,17 mm | 4 |
| 22022106G | 5093904AA | Gasket intake / exhaust manifold | 1 |
| 22022107F | 5066786AA | Gasket valve cover | 1 |
| 22022147F | 5142656AB | Gasket oil pan | 1 |
| 22022144F | 5142815AA | Gasket EGR valve | 1 |
| 22022145F | 5142816AA | Gasket oil cooler | 1 |
| 22022146F | 5142617AA | Gasket EGR cooler | 1 |
| 22032176F | 4720300 | Gasket oil filler cap | 1 |
| 22032246F | 4864575 | Gasket water pump | 1 |
| 22032268F | 5066806AA | Gasket thermostat | 1 |
| 22032269F | 5066946AA | Gasket air intake elbow | 1 |
| 22032274G | 5066921AA | Gasket timing cover | 1 |
| 22032286F | 5142613AA | Gasket EGR valve | 1 |
| 42020010A | 4720713 | Washer | 4 |
| 42020012A | 4720703 | Washer | 4 |
| 42020014A | 4720704 | Washer | 4 |
| 42020018A | 4720564 | Washer | 1 |
| 42020019A | 4720353 | Washer oil drain plug | 1 |
| 42020024A | 5015040AA | Washer | 1 |
| 42020025F | 5142808AA | Washer | 1 |
| 42020033A | 5066853AA | Gasket | 1 |
| 42020042A | 5066811AA | Washer | 2 |
| 45062027F | 5072722AA | Washer injector fuel | 4 |
| 46320006A | 4720373 | Oring engine oil indicator | 1 |
| 46320029A | 5066887AA | Oring | 1 |
| 46320205A | 5093955AA | Oring cylinder liner 1,70 mm black | 8 |
| 46320211A | 5083157AA | Oring injector fuel | 1 |
| 46320241A | 4720626 | Oring cylinder liner 1,70 mm brown | 4 |
| 46320255F | 5066860AA | Oring | 3 |
| 46320256F | 5066763AA | Oring crancshaft rear black | 1 |
| 46320262F | 5072707AA | Oring | 1 |
| 46320265F | 5066789AB | Oring | 2 |
| 46320266F | 5096232AA | Oring | 1 |
| 46320268F | 5114347AA | Oring | 2 |
| 46320269F | 5159019AA | Oring water pump | 1 |
| 46320271F | 5142806AA | Oring EGR valve | 1 |
| 46320514A | 5066899AA | Oring | 3 |
| 22022151F | 5142657AB | Gasket turbocharger | 1 |
| 46320270F | 4720277AA | Oring crancshaft rear blue | 1 |
| 22022155F | 68020548AA | Gasket turbocharger | 1 |
| 22032141G | 4796007AB | Gasket turbocharger | 1 |
| 46320211A | 5083157AA | Oring injector fuel | 4 |
| 42020016A | 4797784 | Washer | 1 |
